AER dMEV Fan

The AER dMEV Fan is a decentralised, continuously mechanical extract fan designed for bathrooms, kitchens, and utility rooms. Its ultra-quiet, low-energy operation ensures effective air extraction while keeping energy consumption to a minimum. Featuring intelligent automatic humidity control, the fan boosts airflow in response to sudden rises in moisture, preventing unnecessary heat loss and noise. The unit offers adjustable speeds for precise commissioning, making it an ideal solution for residential spaces.

Timer Control

Humidity Control

PCDB Listed

Models

Description

Code

Axial dMEV Fan 100/4″ with Timer and Humidistat

10208

Axial dMEV Fan 100/4″ Low Voltage with Timer and Humidistat

10209

Axial dMEV Fan 150/6″ with Timer and Humidistat

10216

Features and Benefits

Key Features

Modern design: sleek front cover, easily removable for cleaning and inspection.
Energy-efficient: ultra-quiet, low-energy fan/motor assembly for optimal ventilation.
Certified performance: listed in the Product Characteristics Database (PCDB).
Customisable speeds: multiple settings for precise commissioning to desired ventilation rates.
Multiple sizes: available in 100mm and 150mm options.
Constant flow function: ensures consistent airflow and compensates for resistance.
Smart humidity control: automatically adjusts fan speed to prevent heat loss, excess energy use, and noise.
Intelligent run-on timer: activates only if the boost function has been running for 3+ minutes to save energy.
IPX4 rated.

Technical Features

Durable ABS casing: Long-lasting, shock-proof, and robust construction.
UV resistant finish: white RAL 9010 color, designed to resist discoloration.
Advanced impeller design: winglet-type impeller for superior aerodynamics, low noise, and high efficiency.
High-performance EC motor: brushless motor with integral thermal protection, mounted on sealed-for-life ball bearings for longevity.
Cold climate ready: reliable operation even in low temperatures.
Optimised airflow: stator with aerodynamic deflectors to minimise turbulence and maximize efficiency.
Eco-friendly: fully recyclable plastic components.
Double insulated: no earth connection required.

Performance Data
