CA Metal In-Line Fan

Technical Features

• Pickled, phosphate-coated steel sheet casing that has been painted with polyester paint against aggressive weathering.
• Motor-holder built into the boxes housing the mains connection terminals and the flow conditioner fins, constructed in self-extinguishing plastic resi (V0).
• 3-speed fans that can be set using optional device TRIO-CA (code 12869).
• AC motors with thermal overload cut-out and shafts turning on ball bearings to guarantee long lasting continuous service (at least 30,000 h) at the maximum plate temperature.
• Backward-curve, heat resistant plastic resin blade impellers loaded with glass fibre to combine structural strength and dimensional stability.
• Possibility of connecting to remote environmental temperature, humidity, smoke and presence sensors (optional).
• Galvanised steel sheet brackets for wall, ceiling and false ceiling installation.
• Protection rating from dusts and water: IP44 (appliance ducted in extraction and delivery).
• Insulation Class: II .
