The A-E plate fans are compact, plate-mounted axial fans designed for wall or panel installation. Engineered for low-pressure applications, these fans provide efficient airflow with low noise emissions. Available in both single-phase and three-phase versions, they offer versatility for different power requirements and can be used in both direct and ducted extraction systems.
Models
Description
Code
Plate Axial Fan 250 Single Phase
41220
Plate Axial Fan 300 Single Phase
41221
Plate Axial Fan 350 Single Phase
41222
Plate Axial Fan 400 Single Phase
41223
Plate Axial Fan 450 Single Phase
41224
Plate Axial Fan 500 Single Phase
41225
Plate Axial Fan 500 Single Phase
41226
Plate Axial Fan 550 Single Phase
41228
Plate Axial Fan 630 Single Phase
41230
Plate Axial Fan 500 Three Phase
41227
Plate Axial Fan 550 Three Phase
41229
Plate Axial Fan 630 Three Phase
41231
Ventilation ports integrated into the wall panels as a single, unified piece.Elongated design to optimise airflow, improving ventilation efficiency.
Safety and anti-bird grilles designed according to the UNI ISO 13857 safety standard. Motor bracket function built into the protective grille. and made from electrically welded steel with an epoxy black paint finish. The grilles are easily removable for quick maintenance and cleaning.
Class F thermally protected asynchronous motors for enhanced performance and longevity.
Double-shielded ball bearings support the motor shaft, ensuring smooth, reliable operation.
IP54 protection rating, meaning it is resistant to dust and water, suitable for tough environments.
Adjustable speed through Vortice controllers, allowing for customisable ventilation.
Single-phase models include starting capacitors that meet the EN 60252-1 standard, with third-party certification for safety and reliability.
Features a variable number of blades (4 to 7 depending on the model).
